J30J-25ZKWP Micro-D Connector | 25-Pin 90° PCB Receptacle, Brass Coupling Nut

Part Number:J30J-25ZKWP

Product Description:

MIL-DTL-83513 Micro-D Connectors Product Overview

The MIL-DTL-83513 Micro-D Connectors, also known as J30J-25ZKWP, are high performance connectors designed for rugged and reliable operation in harsh environments. They are commonly used in military, aerospace, and industrial applications.

Product Attributes:

• Gender: Receptacle

• Operating Temperature: -55 to +125°C

• Current Rating: 5A

• Connector Type: Micro-D

• Voltage Rating: 500V

Key Features:

• Receptacle with socket design for secure connections

• 90° PCB orientation for space-saving installation

• Gold plated contacts for superior conductivity and corrosion resistance

• 4 rows of contacts for high density and compact size

• 25 contacts for versatile use in various applications

• Passivated for added protection against environmental factors

• Rugged construction for durability in harsh conditions

• Reliable performance for critical operations

With its high current and voltage ratings, versatile design, and rugged construction, the MIL-DTL-83513 Micro-D Connectors are the ideal choice for demanding applications that require secure and reliable connections in extreme environments.

Features:

• Product Name: MIL-DTL-83513 Micro-D Connectors

• Coupling Nut: Brass

• Contact Plating: Gold Over Nickel

• Shell Material: Aluminum

• Contact Material: Copper Alloy

• Mating Cycles: 500

• Rectangular Connectors

• Rectangular Connectors

• Rectangular Connectors

Technical Parameters:

Applications:

MIL-DTL-83513 Micro-D Connectors

Brand Name: TUO HANG
Model Number: J30J-25ZKWP
Place of Origin: China
Current Rating: 5A
Connector Type: Micro-D
Number of Contacts: 25
Voltage Rating: 500V
Coupling Nut: Brass

Product Description

The MIL-DTL-83513 Micro-D Connectors, manufactured by TUO HANG in China, are high-performance, military-grade connectors designed for use in various applications. These miniature connectors have 25 contacts and a current rating of 5A, making them suitable for high-density and high-performance applications. Their compact size and durable materials make them ideal for use in harsh environments.

Application and Usage

The MIL-DTL-83513 Micro-D Connectors are commonly used in military and aerospace industries, as well as in medical, industrial, and communication equipment. They are specifically designed for use in 90° PCB mount applications, providing a secure and reliable connection between the PCB and other components. These connectors can also be used in conjunction with other TUO HANG products, such as cable assemblies and backshells, to create a complete interconnect solution.

Features and Benefits

• 90° PCB Mount: The 90° angle of the PCB mount allows for easy installation and ensures a secure connection.

• Receptacle with Socket: The receptacle with socket design provides a reliable electrical connection between the connector and the mating component.

• High Density: With 25 contacts, these connectors offer a high density solution for applications with limited space.

• Miniature: The compact size of these connectors makes them ideal for use in small and tight spaces.

• High-Performance: These connectors are designed to meet the rigorous standards of military and aerospace industries, ensuring reliable performance in demanding environments.

• Military-Grade: The MIL-DTL-83513 specification guarantees that these connectors meet the strict requirements for military-grade equipment.

Conclusion

The TUO HANG MIL-DTL-83513 Micro-D Connectors are a reliable and high-performance solution for a wide range of applications. Their compact size, high density, and durability make them an ideal choice for military, aerospace, and industrial use. With the added assurance of being military-grade, these connectors are a top choice for demanding environments.
