MIL-DTL-26482 Series I Straight Plug | High-Reliability Aviation Circular Connector

Miniature Connector MIL-DTL-26482 Series Ⅰ； Straight Plug; MS3116E22-55PN.Olive Drab Cadmium

Part Number:MS3116E22-55PN

Product Description:

MIL-DTL-26482 Series Ⅰ is a high-performance MS3116E22-55PN plug connector certified for use in a variety of military and aerospace applications. It features a voltage rating of 500V, a current rating of 7.5A, and a contact termination of solder. Its shell finish is olive green cadmium and provides reliable performance in harsh environments. The MIL-DTL-26482 Series Ⅰ is designed to meet the strict requirements of the military and aerospace industry, ensuring maximum durability and longevity.

Features:

• Product Name: MIL-DTL-26482 Series Ⅰ

• Number of Contacts: 55

• Shell Material: Aluminum Alloy with an olive green cadmium finish

• Current Rating: 7.5 A

• Voltage Rating: 500V

• Style: Straight plug

Technical Parameters:

Product Pictures

Applications:

The TUO HANG MS3116E22-55PN is a straight plug connector with 55 contacts and a 7.5A current rating. This connector is designed for applications up to 500V and features a red insulation and an olive green cadmium shell finish. This durable and reliable connector is ideal for a variety of industrial and commercial applications. The TUO HANG MS3116E22-55PN is perfect for use in harsh and demanding environments and is designed for maximum performance and reliability.

Customization:

TUO HANG MIL-DTL-26482 Series Ⅰ connectors are high-quality MIL-DTL-26482 Series Ⅰ connectors with the model number MS3116E22-55PN. They provide current ratings of up to 7.5 A and have a voltage rating of 500V. The connectors are made of aluminum alloy and are designed for plug applications. These MIL-DTL-26482 Series Ⅰ connectors are made in China and are designed for reliable and efficient connections.

Support and Services:

MIL-DTL-26482 Series Ⅰ product technical support and services include:

• Providing product information and technical documents

• Assisting with product selection and design

• Providing product installation and troubleshooting assistance

• Providing product repair and maintenance services

• Providing software upgrades

• Providing technical training

Packing and Shipping:

MIL-DTL-26482 Series Ⅰ Packaging and Shipping:

The MIL-DTL-26482 Series Ⅰ connectors are shipped in a sealed package of non-corrosive material which is suitable for long-term storage. The connectors are shipped in a padded envelope or other suitable packaging material to ensure safe delivery.

For larger orders, MIL-DTL-26482 Series Ⅰ connectors are shipped in a box or on a pallet with suitable cushioning material to prevent any damage during transit.

FAQ:

• Q: What is the brand name of MIL-DTL-26482 Series Ⅰ?
  A: The brand name of MIL-DTL-26482 Series Ⅰ is TUO HANG.

• Q: What is the model number of MIL-DTL-26482 Series Ⅰ?
  A: The model number of MIL-DTL-26482 Series Ⅰ is MS3116E22-55PN.

• Q: Where is MIL-DTL-26482 Series Ⅰ manufactured?
  A: MIL-DTL-26482 Series Ⅰ is manufactured in China.

• Q: What kind of product is MIL-DTL-26482 Series Ⅰ?
  A: MIL-DTL-26482 Series Ⅰ is a type of electrical connector.

• Q: What is MIL-DTL-26482 Series Ⅰ used for?
  A: MIL-DTL-26482 Series Ⅰ is used to provide power and signal connection between two circuits.

MIL-C-26482 Series 1 Datasheet.pdf
